FingerTech 'Viper' Lifter Add-On
FingerTech 'Viper' Lifter Add-On
  (Enlarge)
  • Description
  • CAD Files
  • Reviews
  • Related
Take your Viper Combat Robot kit to the next level by adding a powerful servo-actuated lifting arm!

Specifications:
Lift Height: 19cm (7.5in) - 90 degrees (can self-right from upside down!)
Weight: 117grams (4.1oz) - added onto the Viper base, the total will be 427grams (15.1oz).
Voltage: The servo can operate up to 9V.
   - The 7.4V battery used for the Viper kit works great.  If you wish to run the Viper off an 11.1V lipoly battery, a 9V regulator must be added.

Kit Includes:
Servo: GS-5515MG servo with FingerTech Servo Mounts
Lift Arm: Spring steel Scoop and Linkage, Polycarbonate arms, threaded Crossbar, two 2x1 Mini NutStrip pieces
Screws: Nine 4-40x0.25", eight 6-32x0.25" and four 6-32x0.5" screws plus hex wrench.
Instructions: Detailed instructions with pictures. (Download here)(Download here)

Requires:
- Threadlock liquid
- Electrical tape
- Phillips screwdriver

1 Product Reviews - Average rating 5 / 5 (Show All)

Click to review this product

Simple & powerful kit

- 29th January 2018

Very impressive kit.
Simple to install, strong, appears solid (based on garage skirmishes with other lifters, not full-on battle with spinners), adds self-righting capability.

After building 3 kits, I have the following comments/recommendations:
1 - Use servo L-bracket holes 1 & 4, not 2 & 5.
2 - When attaching the Viper top armor, slide the armor left/right so that the arm screw does not contact the top armor, then torque the armor screws.
3 - Add washers to the lift arm/small nut strip joints to minimize the chance that these screws will back out or tighten when operating the arm.
4 - Add a nut to the servo arm/lift arm joint & torque it to the servo arm to minimize the chance that this screw will back out or tighten when operating the arm.
5- Set Tx channel 3 endpoints to 120% or the arm will not move far enough upward to self-right. [Already done if Tx purchased from FingerTech]
6 - Do not mount a power indicator LED on the back wall of the Viper. It will stick out just barely enough to drag on ...
